Fiberglass AI Visual Inspection Equipment
Fiberglass AI visual inspection equipment targets fiberglass cloth / mat, performing inline inspection of yarn breakage, missing weft, stains, thickness, fuzz, holes, poor overlap and other defects, with OK/NG output and production line interlocking.
Materials Overview
Transparent fiber + resin, with the focus on fuzz and overlap
Fiberglass AI visual inspection equipment images fiberglass fabric or mat; the algorithm identifies defects such as yarn breakage, missing weft, stains, thickness anomalies, fuzz, holes and poor overlap, outputs OK/NG results and interlocks with the production line.
Fiberglass cloth / mat is woven or laid from glass fiber; the fiber itself is nearly transparent with a silky sheen and is often combined with resin. Its difficulty is "transparent fiber + fuzz": fuzz is a single fiber standing up, with weak contrast against a nearly transparent background; poor overlap (misalignment when laying multiple plies) also requires alignment judgement.
Defects specific to fiberglass include yarn breakage, missing weft, stains (resin spots or oil stains), uneven thickness, fuzz, holes and poor lapping. Fuzz and yarn breakage affect the surface and strength of the subsequent part and are key items.
Inspection uses AI to build a model of the normal weave / web formation and judges yarn breakage, fuzz and lap offset as defects; changing the weave (plain / felt) mainly requires adjusting the recipe.
Applicable Type
Fiberglass Plain Weave
Focus on yarn breakage and missing weft
Fiberglass Mat
Laid-web structure, key points: thickness and fuzz
Fiberglass Composite
Resin-containing, the focus is on stains and overlaps
Fiberglass Rolls
Continuous material feed, line-scan full-width inspection
Fiberglass Cut Pieces
Already cut, inspected piece by piece with defect locating
Common defect
| Defect Types | Typical Manifestations | Inspection Focus Points |
|---|---|---|
| yarn breakage | Warp / Weft Breakage | Compare With Weave Pattern |
| Missing weft | Missing Weft Yarn | Weft-direction Feature |
| stain | Resin Spots, Oil Stains | Compared against transparent background |
| Uneven Thickness | Local Thickness Variation | Region Statistics |
| fuzz | Filament Lifting | Weak against near-transparent background |
| hole | Short Shot or Penetration | Transmitted Light Is the Most Direct |
| Poor Overlap | Multi-Layer Misalignment | Requires Alignment Datum |
| foreign matter | Stray Fibers, Particles | High-contrast Features |
inspection Workflow
Complete chain from loading to judgment
- 01 Fiberglass loading / roll unwinding or cut-piece feeding
- 02 Flattening and tension control
- 03 Triggered Imaging
- 04 Weave pattern / lay-up modeling
- 05 Anomaly region segmentation
- 06 Defect classification and grading
- 07 Overlap alignment check
- 08 Synthesized OK / NG
- 09 Marking / rejection and image archiving
AI Inspection Principles
AI Visual Inspection Principles
Fiberglass inspection is difficult because of "transparent fiber + fuzz". The algorithm builds a model of the normal weave / laid web and classifies yarn breakage, missing weft, fuzz and lap offset as defects. Fuzz has weak contrast against a near-transparent background, so sufficient resolution and suitable illumination are needed.
For illumination, diffuse light gives uniform lighting to see stains and thickness; backlight is used for holes; low-angle light exposes fuzz and surface relief. With transparent fibers, reflection interference must be controlled.
For judgement, we recommend setting yarn breakage and fuzz as high priority and judging laps by offset tolerance. Specific thresholds must be confirmed by measured testing of OK / NG samples.
Applicable Industry
Applicable equipment
Common Question
Why is fuzz on glass fiber difficult to inspect?
Is inspection the same for fiberglass cloth and fiberglass mat?
Can Poor Lapping Be Detected?
Can the internal resin condition be detected?
What is the inspection accuracy?
What samples are needed to develop a solution?
Can It Be Integrated Into an Existing Production Line?
Submit sample testing
Send OK and NG samples of different types such as glass fiber cloth and glass fiber mat, and we will run measured tests on fuzz and overlap, and provide an illumination plan and judgement recommendations.
